Silver's Neomax Coilovers - BMW M5 E60 05-10
SKU: SB123
$1,599.00 AUD $1,599.00 AUD $1,599.00 AUD
Shipping calculated at checkout.
Model Neomax S
Usually Ships In 2 Weeks

Features a carbon steel 52mm diaseamless tube with a 44mm linear characteristic internal piston.

Height adjustment can be performed either with spring perch or base mounts.

Coil springs are cold-bent and made from high strength SAE9252 steel.

Silvers come standard with 12 months warranty. Additional 6 month warranty is available when protection boots are used.
Scroll to section

Description

Silver's Suspension was established in 1999, born out of years of racing in time attack competitions and the continuous search for an optimal suspension setup. Recognizing significant shortcomings in the existing market offerings, the founders embarked on a journey filled with trials and tribulations, ultimately leading to the creation of Silver's.

Silver's Suspension blends a passion for automotive racing with extensive industry knowledge. From its inception, the company has maintained a steadfast commitment to prioritizing performance. Each suspension kit is meticulously designed with track performance and reliability as dual focal points.

All Silver's Suspension kits, where applicable, feature standard adjustments for dampers, springs, and bases, allowing users to fine-tune their desired setup. For compatible vehicles, Silver's Coilovers come equipped with front camber adjustable top mounts for enhanced adjustability. The Neomax R and Competition 2-Way Adjustable coilovers also include rear camber adjustable top mounts. Additional features such as mono-tube carbon steel body shock absorbers, pillow-ball top mounts, and radial bearings contribute to a high-performing coilover that significantly enhances your vehicle's handling capabilities.

Silver's Suspension offer a minimum of three Coilover models for all vehicles: Neomax S, Neomax Black Edition, and Neomax R. For certain vehicles, Silver's Suspension offer additional Coilover kits in the way of Neomax Super Low and Neomax Competition 2 Way Adjustable. See below for more information on each available set for your vehicle.

Neomax S

Sport Tuned Suspension System

Silvers Neomax S coilovers bring a feature packed, monotube coilovers system at an affordable price.

Fully Adjustable

Silvers Neomax S coilovers offer damper adjustment, spring preload adjustment and lower mount adjustment as standard.

Front Camber Adjustment

For vehicles which allow front camber setting via the top plate (for
example MacPherson Strut vehicles), Silvers Neomax S coilovers include
camber adjustable top mounts as standard.

40 Levels of Damper Adjustment

To allow for accurate setting of dampening, Silvers Neomax S coilovers offer 40 levels of adjustment via the adjustment knob.


Neomax Black Edition

The same features, plus more

Neomax Black Edition coilovers offer all the same great features as Neomax S, but with a few extras.

Stealth Black Appearance

Silvers Black Edition coilovers offer a unique appearance with every
component being finished in a black coating, including the inner shock
tube and top mounts.

12 Level Damper Adjustment

To allow for faster and
easier adjustment, Neomax Black Edition coilovers have 12 levels of
damper adjustment with each 'click' offering an effective change in
dampening performance.


Neomax R

Track Day Performance

Neomax R coilovers offer the same features as Neomax S but with a more track focused approach.

20W Damper Oil

Neomax R coilovers use a 20W damper oil rather than the 10W oil utilised on S and Black Edition coilovers. This allows for additional temperature resistance,
reliability and performance in demanding situations such as motorsport.

Rear Camber Adjustment

In addition to the standard front camber platers, for vehicles which allow rear camber setting via the top plate (for example MacPherson Strut vehicles),
Silvers Neomax R coilovers include camber adjustable top mounts as
standard.

Custom Spring Rates & Setup

At no extra cost, Silvers Neomax R coilovers can be assembled with your choice of spring rates and use any notes you have to set up accordingly.


Standard Features

Vehicle Compatibility

Vehicle Specific Specifications

Neomax S

  • Front Spring Rate: 12K
  • Rear Spring Rate: 11K-S


-S = Separated shock & spring assembly


  • 40 levels of dampening adjustability.
  • IP F.A. 20W damper oil.
  • Mono-tube shock design
  • JIS G3445-STKM13C(DIN2393-ST44-2) carbon steel 52mm diaseamless tube
  • 44mm linear characteristic internal piston
  • Cold-bent springs made from high strength SAE9252 steel.
  • Lower bracket height adjustability prevent the need to adjust the spring perch, offering the maximum shock-absorbing travel.
  • Powder painted steel lower bracket can match all design of brake line and ABS line holder, easy for intalling.


Neomax R

  • Front Spring Rate: 14K
  • Rear Spring Rate: N


-S = Separated shock & spring assembly


  • 40 levels of dampening adjustability.
  • IP F.A. 20W damper oil.
  • Mono-tube shock design
  • JIS G3445-STKM13C(DIN2393-ST44-2) carbon steel 52mm diaseamless tube
  • 44mm linear characteristic internal piston
  • Cold-bent springs made from high strength SAE9252 steel.
  • Lower bracket height adjustability prevent the need to adjust the spring perch, offering the maximum shock-absorbing travel.
  • Powder painted steel lower bracket can match all design of brake line and ABS line holder, easy for intalling.


Neomax Black Edition

  • Front Spring Rate: 12K
  • Rear Spring Rate: 11K-S


-S = Separated shock & spring assembly


  • 12 levels of dampening adjustability.
  • IP F.A. 20W damper oil.
  • Mono-tube shock design
  • JIS G3445-STKM13C(DIN2393-ST44-2) carbon steel 52mm diaseamless tube
  • 44mm linear characteristic internal piston
  • Cold-bent springs made from high strength SAE9252 steel.
  • Lower bracket height adjustability prevent the need to adjust the spring perch, offering the maximum shock-absorbing travel.
  • Powder painted steel lower bracket can match all design of brake line and ABS line holder, easy for intalling.


Neomax 2 Way Adjustable Competition

  • 40 levels (rebound) x 24 levels (compression) of dampening adjustability.
  • IP F.A. 20W damper oil.
  • Mono-tube shock design
  • JIS G3445-STKM13C(DIN2393-ST44-2)carbon steel 52mm diaseamless tube
  • 44mm linear characteristic internal piston
  • Cold-bent springs made from high strength SAE9252 steel.
  • Lower bracket height adjustability prevent the need to adjust the spring perch, offering the maximum shock-absorbing travel.
  • Powder painted steel lower bracket can match all design of brake line and ABS line holder, easy for intalling.
